Motorized Foam Transfer Pump

The pump body is equipped with a pair of main and passive wheels, the driving wheel is driven by the engine to rotate, and the two gears are engaged with each other. The internal space of the pump is divided into two working chambers. A is the suction cavity and B is the discharge cavity. The two gears rotate. When the teeth of a wheel are engaged to disengage, a partial vacuum is formed in the suction cavity, and the liquid is sucked in. The sucked liquid fills the tooth valleys of the gears and is brought to the discharge. When the gears continue to enter the occlusion cavity, the liquid is squeezed out, and the high-pressure liquid is formed repeatedly and discharged through the discharge port.

It is mainly used for the addition and transfer of foam liquid during and after the war; in special circumstances, it can also be used for fire rescue and transfer of viscous liquids.

Remarks: Store product parameters, prices, freight, etc. are subject to actual communication. Please contact customer service to verify specific parameters, prices, and freight before purchasing.

Share:

Please note that we accept the following payment methods: Commercial Letter of Credit / Credit Card / PayPal and PayPal Secured Transaction etc. Thus ensuring your payment is safe and secure. We guarantee that the goods can be delivered safely.



Product Description

Specification
Model SZQ-200
Engine Mode Four-stroke single-cylinder air-cooled
Engine Way Four-stroke double cylinder air-cooled
Engine Type Gasoline Gasoline
Rated Power 5.5KW
Starting Model Starting Model Electric start/ hand pull Electric/hand
Self-Priming Depth ≥ 3 meters (excessive depth requires liquid introduction)
Fuel Tank Capacity 4.5L
Rated Capacity 200L/min
Lift ≥30 meters
Inlet Diameter 50mm
Outlet Via Outlet Diameter 50mm
Net Weight 78KG
Dimensions 800*550*560mm
